It is important to keep in mind that we are not able to test the LSI 9280-8E to its full potential. The ARC-1680 Series of products is very popular with enthusiasts because of its high speed and low cost. Because of this we were never able to get the most out of the LSI 9280-8E, but expanders with SAS 2.0 technology are on the horizon.įor comparison we used an Areca ARC-1680X controller that runs on a PCIe 1.0 bus and uses SAS 1.0 technology. The iT8SAE is built very well and it received a very high score in our review, but the built in expander was only able to run at SAS 1.0 speeds. You can read more about TweakTown's Storage Product Testing Workstation and the procedures followed to test products in this article.įor testing we used the iStoragePro iT8SAE 8-bay SAS expander with eight Seagate 15K.7 drives.
Lsi megaraid storage manager in safe mode windows 7#
Operating System: Microsoft Windows 7 Ultimate X64 SAS Controller: Areca ARC-1680X (Supplied by Areca Technology) SAS Controller: LSI MegaRAID SAS 9280-8E (Supplied by LSI) Graphics Card: Leadtek Quadro FX1700 (Supplied by Leadtek)Ĭooling: Noctua NH-U12P SE2 (Supplied by Noctua) Memory: Corsair Dominator 1600 MHz Triple Channel Kit Processors: Intel 975 EE (Supplied by AVADirect) Motherboard: ASUS P6T7 WS SuperCoputer (Supplied by ASUS)
Lsi megaraid storage manager in safe mode software#
Also included is a pair of software disks that have the drivers, software and detailed manuals. LSI includes a quick start guide, a low profile bracket and instructions for changing the brackets. The MSRP for the 9280-8E was set at 859 USD, but we were able to find it as low as 700 USD and Newegg currently has retail stock at 744.99. When it comes to availability, we found several e-tailers carrying the new 9200 Series products.
Lsi megaraid storage manager in safe mode drivers#
LSI also offers drivers for just about every operating system including Linux and Apple. LSI includes software to configure the controller and the amount of control given to the user is staggering. To further increase the speed of the storage system, the 9280-8E has 512 MB of 800 MHz DDR2 SDRAM built into the card. Since SAS 2.0 doubles the available bandwidth per lane, it is possible to see significant performance increases when SAS 2.0 expanders are also used. The 9280-8E is able to expand to 240 drives total. Each SFF-8088 port passes 4 lanes that can then be expanded with SAS expanders or port multipliers. The 9280-8E uses two SFF-8088 miniSAS ports on the back of the card that connect to external enclosures via a miniSAS cable.
By moving to PCIe 2.0 technology LSI was able to double the bandwidth to the host system and still keep the 8x lane connector. With the introduction of solid state and very high performance 15K drives, we were able to reach the limits of PCIe 1.0 with as few as four drives. For the first time PCIe 2.0 technology was used and it doubles the bandwidth from the controller to the system.įor the last couple of years we have been able to saturate the PCIe 1.0 interface with eight hard drives. The second technology leap comes from the way the controller interfaces with the motherboard. The first is SAS 2.0, the latest 6Gb/s interface that doubles the amount of available bandwidth per connection to each drive or lane connected to a SAS expander. The LSI 9200 Series of products brought two big improvements to the table that until this point we had not seen before in this product class.
Let's have a look at the specifications of the LSI MegaRAID 9280-8E SAS 2.0 RAID controller. Small companies with a small number of users have found that DAS offers the same disk redundancy features of NAS servers, but offers higher data transfer speeds and in many cases lower costs.
Lsi megaraid storage manager in safe mode professional#
It is going to take the market a couple of months to get these products ready, with availability likely towards the end of Q1 2010.Įxternal SAS enclosures are categorized as Direct Access Storage (DAS) and the technology has now trickled down from enterprise and is a popular way of adding very large disk arrays to professional Audio / Video users. We have already tested both drives on the internal version of the card we are reviewing today, the LSI 9260-8i, and saw large single drive performance increases just by moving to SAS 2.0.Īt this time I was unable to find an external drive enclosure that was able to take advantage of new 6G technology. The Seagate 15K.7 3.5 inch form factor and 15K.2 2.5" drives both showed performance improvements with the new 6G interface. Seagate and LSI teamed up to bring SAS 2.0, 6Gb/s technology to enterprise and prosumer users in late 2009.
